Dobinsons Rear U-Bolt Kit to suit Isuzu D-Max 2nd Gen 2012-2020

UB59-453-2K(X2)

Select your kit type:
Select your model type:
Select your spring rate:
In stock
$140.00
$140.00 $0.00
Tax included.

Disclaimer: It is the purchaser’s responsibility to ensure all products and the installation thereof meet current LVV requirements, where applicable.

A wheel alignment must be performed after the installation of upgraded suspension parts. After a suspension lift or bull bar install, most ADAS (Advanced Driver Assistance Systems) equipped vehicles will require calibration.

It is the purchaser's responsibility to ensure the ADAS re-calibration is carried out by a specialised technician to guarantee the safety of the vehicle and its occupants.

DETAILS

Dobinsons Rear U-Bolt Kit to suit Isuzu D-Max 2nd Gen 2012-2020

Please select your vehicle model from the dropdown menu.

Includes:
- Dobinsons U-Bolts (2x Pairs Required, also sold in individual pairs).

Details:
Dobinsons 4×4 U-bolts are made from high quality, 10.9 grade high tensile steel and supplied with hardened deep nuts for maximum clamping pressure and reliability. It is recommended that when replacing leaf springs that new u-bolts are fitted. Supplied in anti corrosion zinc finish.

Specifications:
UB21-466K
Shape: Round Top
Thread Size: M14
Between Bolt Diameter: 90 mm
Internal Height: 210 mm
Part Reference: UB466 / UB21-466K

UB59-437K
Shape: Square Top
Thread Size: M14
Between Bolt Diameter: 62 mm
Internal Height: 210 mm
Part Reference: UB437 / UB59-437K

UB59-453-2K
Shape: Square Top
Thread Size: M14
Between Bolt Diameter: 62 mm
Internal Height: 180 mm
Part Reference: UB453-2 / UB59-453-2K

Make Model Years
ISUZU D-MAX Series II (TFS85) 2012–2020
