Dobinsons 75mm Gas Lift Kit to suit Toyota Hilux N80 2015-Onwards

N8075GAS-1

Select your chassis type:
Select your front springs:
Select your rear springs:
In stock
$4,380.00
$4,380.00
Tax included.

PRE-ORDER INFORMATION

If this Kit is showing as "Pre-Order" please complete the product enquiry form on this page to confirm which items are out of stock. Sometimes, there is only one item that is out of stock which may be able to be substituted to complete the kit.

Disclaimer: It is the purchaser’s responsibility to ensure all products and the installation thereof meet current LVV requirements, where applicable.

A wheel alignment must be performed after the installation of upgraded suspension parts. After a suspension lift or bull bar install, most ADAS (Advanced Driver Assistance Systems) equipped vehicles will require calibration.

It is the purchaser's responsibility to ensure the ADAS re-calibration is carried out by a specialised technician to guarantee the safety of the vehicle and its occupants.

DETAILS

Dobinsons 75mm Gas Kit Lift to suit Toyota Hilux N80 2015-Onwards

Note 1: This suspension lift kit will NOT fit the Toyota Hilux SR5 Cruiser K-Series models. Please find Lift Kits for the K-Series HERE if you are unsure, please email us with your vehicle registration number.

Note 2: We strongly recommend you run an adjustable coil over when opting for a 75mm front lift. Giving you the ability to make any adjustments as necessary come certification time. These shocks are fixed height only and have 4-Stage Adjustable Damping.

Please use the drop down menu to select your model type, lift amount and the correct spring rates depending on your vehicles accessories.

Type: Hilux
Model: N80
Year: 2015 -
Suspension Type: Coil Spring Front / Leaf Spring Rear
Front Lift: 75mm Lift
Rear Lift: 45-75mm Lift
Detail:
- Twin Tube Nitrogen Gas Charged Shock Absorbers
- Front shocks come pre-assembled for ease of installation.

COMPONENTS

Front:
2x Dobinsons Heavy Duty Front Shocks - GS59-220
1x Pair Dobinsons Front Springs
2x Trundles Strut Mounts - TOP2
1x Trundles Upper Control Arm Set - UCA3881HV2
1x Trundles Arm Style Diff Drop - DDHIL-ARM
1x Front Swaybar Relocation - HIL-073
1x Body Mount Weld in Insert - OUTRIGGER-N80

Rear:
2x Dobinsons Heavy Duty Rear Shocks - GS59-229
2x Dobinsons Rear Leaf Springs
1x Dobinsons Leaf Bush Kit - PB59-1094K
2x Dobinsons U-Bolt Kits - UB59-437K

For a lower replacement bush to fit GS59-220, please click here

WHAT'S INCLUDED
16555 | Dobinsons Heavy Duty Front Gas Shock (Pair) to suit Toyota Hilux N80 2015-Onwards
16555 | Dobinsons Heavy Duty Front Gas Shock (Pair)
14700 | Dobinsons Front Coil Springs to suit Toyota Hilux N80 2015-Onwards
14700 | Dobinsons Front Coil Springs
39373 | Trundles Strut Top Mount to suit Toyota Vehicles 2003-Onwards
39373 | Trundles Strut Top Mount
38505 | Trundles Control Arms V2 to suit Toyota Hilux N70/N80 2005-Onwards
38505 | Trundles Control Arms V2
03159 | Diff Drop Kit (Arm Style) to suit Toyota Hilux N70/N80 2005-Onwards
03159 | Diff Drop Kit (Arm Style)
38786 | Trundles Front Swaybar Relocation (85mm Hole Centers) to suit Toyota Hilux N80 2015-Onwards
38786 | Trundles Front Swaybar Relocation (85mm Hole Centers)
38437 | Trundles Body Mount Mod Weld-In Insert to suit Toyota Hilux N80 2016-Onwards
38437 | Trundles Body Mount Mod Weld-In Insert
16761 | Dobinsons Heavy Duty Rear Gas Shock (Pair) to suit Toyota Hilux N80 2015-Onwards
16761 | Dobinsons Heavy Duty Rear Gas Shock (Pair)
19755 | Dobinsons Rear Bush Kit to suit Toyota Hilux N80 2015-Onwards
19755 | Dobinsons Rear Bush Kit
21058 | Dobinsons Rear Leaf Spring to suit Toyota Hilux N80 2015-Onwards
21058 | Dobinsons Rear Leaf Spring
21712 | Dobinsons Rear U-Bolt Kit to suit Toyota Hilux N80 2015-Onwards
21712 | Dobinsons Rear U-Bolt Kit
VARIANT OPTIONS & OPTIONAL EXTRAS
21443 | Dobinsons Rear Shackles to suit Toyota Hilux N80 2015-Onwards
21443 | Dobinsons Rear Shackles
21314 | Dobinsons Rear Shackle Pins to suit Toyota Hilux N80 Revo 2015-Onwards
21314 | Dobinsons Rear Shackle Pins
21983 | Dobinsons Tail Shaft Spacer Kit to suit Toyota Hilux 2015-Onwards / Fortuner 2005-Onwards
21983 | Dobinsons Tail Shaft Spacer Kit
Make Model Years
TOYOTA Hilux N80 2015–Onwards
