STEDI 40.5" 40 LED Slim Light Bar
Includes:
- 1 x 40.5 Inch ST-X-20L LED Light Bar
- 2 x Steel Side Brackets
- 2 x Steel Sliding Brackets
- 2 x Brace Support Brackets
- Easy-Fit High Beam Wiring Kit | HB3 & H4 piggy-back included.
- Comprehensive 304 Stainless Steel fasteners
- Wiring Instructions
Details:
If you're looking for a driving light that offers near-field spread, keep moving, this is not that. The optical properties of the hooded reflector design is best described as high-beam on steroids. The ST-X excels in the high-speed, high-way application when mid to long-range visibility is critical.
- Significantly minimises adverse reflection from road signs
- Controlled vertical spread minimises reflections off of high-mounted road signs.
- 16x 15W LEDs
- LED Parking / Position Light Function (Amber or White built-in)
- Breather allows pressure equalisation when rapid heat up and cool down cycles occur
- Anodized Polyester Powder Coat
- Weatherproof Deutsch® DTP Connector
- Includes adjustable Side brackets & Sliding bottom brackets
- Includes our Easy-Fit Plug & Play High Beam Wiring Harness with HB3 & H4 adapter (Compatible with both negative and positive switched vehicles)
- Protected against reverse polarity
- Shockproof, IP68 waterproof, UV Shielded
- Protected Against RFI / EMC Interference
- Voltage & current surge protection
- Pulse Width Modulation Thermal Management
Tech Specs:
Voltage: 9-36V
Amperes: 17.2A @ 12V (full power), 3.28A @ 12V (limit power)
Power: 206.4W (full power), 39.36 (limit power)
Lumens: 8400LM (full power), 2327LM (limit power)
Colour Temperature: 5000k
Amp Rating: 0.5a
Photometric Data: 1 lux @ 859m (full power), 1 lux @ 450m (limit power)
Lens Material: Optical Grade, Hard-Coated Lexan
Housing Material: 6063 Extrusion
Ingress Protection: IP68
Candelas: 739582 @ full power, 203337 @ limit power
Connector: 60cm cable with DTP 4in
Operating Temp: -40°C ~ +60°C
Certificates: R112, ref. 50 and R10
Lifespan 50, 000hrs (LM80)
Product Weight: 3.7kg
Shipping Weight: 4.2kg
Disclaimer: It is the purchaser’s responsibility to ensure all products and the installation thereof meet current LVV requirements, where applicable.
