STEDI Type-X EVO 4" LED Spot/Flood Beam Driving Light

STEDI Type-X EVO 4"LED Spot/Flood Beam Driving Light

To view more details about each product please select a tab at the top of this description. When ready select an option from the dropdown menu and add to cart.

Just like its big brothers, the TYPE-X EVO 4" LED Driving Light has arrived in a separate dedicated flood and spot beam pattern, meaning you can mix and match, and have full control of your desired beam to suit your driving. Utilising a more efficient technology from CREE’s XP range of LEDs, TYPE-X EVO offers up to a staggering 285m of light throw down the road, and up to a 140m of light spread out to the shoulders when installed as a pair. Promising an even more intense beam pattern, this is the evolution of driving lights.

STEDI Type-X EVO 4" LED Flood Beam Driving Light

Includes:
1 x STEDI Type-X™ Mini 4" EVO LED Driving Light Flood Beam - ST-01-EVO-402
1 x Protective STEDI™ Black Out Cover
1 x Grey Colour Fascia
1 x Orange Colour Fascia
1 x Type-X™ 4" EVO Bag
Complete Bracket & Stainless Steel Fastener Kit
Fitting Instructions

Tech Specs:
LED: 10 x CREE XPP LED (each)
Raw Lumens: 3,700 (each)
Tested Lumens: 2,500 (each)
Amp Draw: 2.7A @ 12V / 1.35A @ 24V (each)
Power Draw: 27W
Candela:
- 55,000 (each)
- 110,000 (pair)
Beam Pattern: 10 x 30° Spread

Environmental & Durability:
Ingress Protection: IP68 – Submersible up to 3m
Colour Temp (CCT): 5000K
Lumen Maintenance: 30,000 LM-80
Voltage Compatibility: 12V & 24V
Weight: 0.78kg (each)
Operating Temperature: -40°C to 60°C

STEDI Type-X EVO 4"

LED Spot Beam Driving Light

Includes:
1 x STEDI Type-X™ MINI (4") EVO LED Driving Light Spot Beam - ST-01-EVO-401
1 x Protective STEDI Black Out Cover
1 x Grey Colour Fascia
1 x Orange Colour Fascia
1 x Type-X™ 4" EVO Bag
Complete Bracket & Stainless Steel Fastener Kit
Fitting Instructions

Tech Specs:
LED: 10 x CREE XPP LED (each)
Raw Lumens: 3,700 (each)
Tested Lumens: 2,500 (each)
Amp Draw: 2.7A @ 12V / 1.35A @ 24V (each)
Power Draw: 27W
Candela:
- 129,000 (each)
- 258,000 (pair)
Beam Pattern: 10 x 5° Pencil Beam

Environmental & Durability:
Ingress Protection: IP68 – Submersible up to 3m
Colour Temp (CCT): 5000K
Lumen Maintenance: 30,000 LM-80
Voltage Compatibility: 12V & 24V
Weight: 0.78kg (each)
Operating Temperature: -40°C to 60°C
