STEDI LED Lightbar Double Row 8" 12 LED
Note: EASY-FIT Plug & Play High Beam Wiring Harness included.
Includes:
1 x 8inch 12 STEDI Oslon LED Light Bar
2 x Brushed Stainless Steel Side Brackets
1 x Adjustable Sliding Brackets
1x Easy-Fit High Beam Wiring Kit | HB3 & H4 piggy-back included.
1x Cable Tie Pack
1x Wiring Instructions
Details:
- STEDI™ ST4K-12 features 12 of OSRAM’s® finest OSLON® LED, selected for its high luminous flux and perfectly matched optical properties.
- 4 Flood + 4 Spot + 4 Flood reflector distribution on the ST4K forms a remarkable beam that pushes the wide beam out at 50° and spot beam at 5.8° reaching up to a staggering 1 lux @ 363m.
- Crystal White 5700K Colour temperature offers stunning clarity and definition with excellent Colour Rendering Index (CRI).
- Our Pure-Drive™ circuit design allow 97% of input power to go directly to LEDs.
- The Cast face plate and extruded Aluminum heat sinks are finished in 100% Polyester UV and abrasion resistant powder coat, ensuring that our bars won't discolour over time..
- Pressure Equalization vent with Gore® membrane | Protects against water ingress, dust & contaminants.
- IP68 | Dust & Particle tight + Water-proof up to 3 meters – Drown it, we insist!
- Environmentally sealed Deutsch ® DT connector.
- Backed by our no nonsense 5-year replacement warranty.
TECH SPECS
| LED MANUFACTURER | OSRAM (Oslon)® |
| LED COUNT | 12 |
| VOLTAGE | 12V & 24V |
| LENS MATERIAL | Optical Grade, Hard Coated Lexan |
| PEAK INTENSITY (CANDELA) | 132,480cd |
| LUMENS | 2,880 LUMENS |
| HOUSING MATERIAL | A360.0 Cast face plate, extruded Aluminum heat sink |
| AMPERES | 2.5A @ 13.6v | 1.1A @ 24v |
| LIFESPAN | 50,000 |
| FLOOD BEAM | 50° |
| SPOT BEAM | 5.8° |
| INGRESS PROTECTION | IP68 |
| OPERATING TEMP | -40°C to 60°C |
| WEIGHT | 1.020kg |
Included is our acclaimed Easy-Fit Plug and Play Wiring Harness with supplied H4 and HB3 Adapters making for an easy connection to high beam. Furthermore, unlike other brands our kit has built in electronics allowinhg our harness to be compatible with even the most modern and sophisticated wiring systems. Whether your vehicle is positive or negatively switched our harness will work right out of the box without any modification whatsoever.
