STEDI 41.5" 40 LED Slim Light Bar

STEDI 41.5" 40 LED Slim Light Bar

Includes:
- ST3K 41.5inch LED Light Bar
- Stainless Fasteners
- Stainless Steel Side Mounting Brackets
- 12v Quick Fit to High Beam Wiring, Relay, Wiring Kit and On/Off Switch
- H4 and HB3 adapters included
- Wiring Instructions

Details:
- ST3K-40L features 40 of OSRAM’s® finest OSLON® LED, selected for unrivalled efficiency.

- 8 Flood + 24 Spot + 8 Flood reflector distribution forms a remarkable beam that pushes the wide beam out at 50° and spot beam at 5.8° all the way to staggering 1 lux @ 699m

- True White 5700K Colour temperature offers stunning clarity and definition.

- Our Pure-Drive™ circuit design allows 97% of input power to go directly to LEDs.

- Finished in 100% Polyester UV and abrasion resistant powder coat ensures that our bars will never discolour.

- Pressure Equalization vent | Protects against water ingress, dust & contaminants.

- IP68 | Dust & Particle tight + Water-proof up to 3 meters!

- Environmentally sealed Deutsch DT-2 connector.

- Protected against EMC and RFI.

- Includes our Easy-Fit High Beam Plug and Play Wiring Harness which includes H4 and HB3 Adapters making for an easy connection to high beam. Unlike the copycat harnesses on the market, ours has built-in electronics making our harness compatible with even the most modern and sophisticated wiring systems

- Backed by a 5 Year Replacement Warranty.

Tech Specs:
LED: 40 x Osram Oslon White
Effective Lumen: 8,250Lm
Peak Intensity (Candela): 486,400cd
Operating Voltage: 10-30V DC
IP Rating: IP68
Current Draw: 8.6A @ 13.6v
Colour Temperature (CCT): 5700 Kelvin
Housing Material: Aluminium Extrusion & Cast
Lens: GE™ Lexan
Mounting Bracket: Powder Coated 3mm Stainless Steel
Bolts and Fittings: 3 Series Stainless Steel
Beam Type: Flood Spot Combo
Life Span: 50,000 Hours
Weight: 3.475kg
Operating Environment: -40 - +50° Celsius

Photometric Data
10m: 4,886 Lx
50m: 195 Lx
100m: 46 Lx
200m: 11.5 Lx
699m: 1 Lx
